Starlite S

Proiettore ad alta efficienza con ottiche intercambiabili per adattarsi alle più diverse esigenze: dalla facciata di un'abitazione alla linea di produzione.

Eficiencia energética

Source efficiency 192 lm / W @ 160mA 4000 ° K
Net effective efficiency 156 ~ 165 lm / W
LED power supply current <100mA
Optical group PMMA lenses
Color temperature 3000 ° K / 4000 ° K / 5700 ° K
Color Rendering Index > 70,> 80
Photobiological risk Exempt Group
LED diode life > 100,000 hh L90B05
Color RAL 7042
Gasket Pure silicone
Guarantee 10 years

Datos técnicos

power supply Multiple on single chip, integrated into the LED board
Supply 230Vac ± 10% 50/60 Hz
Insulation class Class II
PF > 0.98
Degree of protection IP66
Resistance index IK08
Operating Temp. ° C -30 ° / + 50 ° C
Power connection Pre-wired 1,5m cable (other sizes on request)
Apparatus assembly Ceiling, wall, suspension
Tilt adjustment Bracket with rotation ± 100 °
Body material Powder coated UNI1706 aluminum alloy
Screen 5mm ultra bright tempered glass
TLC ready Opt.
Card protection Ultra-fast fuse, MOV
SPD protection 10kV

PLANTILLA:
STL02

DIMENSIONES:
328x198x178 mm

PESO:
3.2 kg

PLANTILLA:
STL04

DIMENSIONES:
328x198x178 mm

PESO:
3.2 kg

Versiones

  Código Energía
@ 230 Vac
° kelvin Fuente
corriente
Dispositivo
de flujo
Eficiencia CRI Dimensiones
Peso

STL02 50 W 3000 / 4000 / 5700 9600 lm 7800 lm 156 lm/W >80 328 x 198 x 178 mm
3,2 kg
ldt
STL04 100 W 3000 / 4000 / 5700 19200 lm 23100 lm 154 lm/W >80 328 x 198 x 178 mm
3,2 kg
ldt
